China Fk (R) N12-12D Indoor Load Break Switch Load Breaker Isolator Isolate Switch Manufacturer, Supplier, Factory

The NS250 Polyfast switchgear accessories are essential components designed to enhance the functionality and safety of electrical switchgear systems. Engineered for robustness and reliability, these accessories are specifically tailored for the NS250 series, ensuring compatibility and optimal performance.

Our company is a leading provider of Switchgear Protective Covers, offering innovative solutions to enhance the safety and reliability of electrical systems. We specialize in designing and manufacturing protective covers that safeguard critical switchgear components from environmental hazards and accidental contact. Our products are crafted from high-quality, durable materials, ensuring long-lasting protection in various industrial settings. By prioritizing safety and quality, we deliver covers that meet stringent industry standards, supporting the seamless operation of electrical networks worldwide.

Product Introduction: Guide Frame Assembly for Switchgear The Guide Frame Assembly for Switchgear is an essential structural component that ensures the smooth and precise operation of switchgear drawers and compartments. This assembly is designed to align, guide, and secure the moving parts of switchgear systems, particularly in withdrawable units. It provides stability during insertion and withdrawal of circuit breakers or other functional modules, minimizing operational risks such as misalignment or mechanical jamming. Manufactured from high-grade materials such as stainless steel or galvanized metal, the frame offers exceptional resistance to corrosion and mechanical wear, which extends the lifespan of the switchgear. Some assemblies feature pre-drilled holes or adjustment slots to accommodate easy installation and fine-tuning. This ensures compatibility with various switchgear brands and modular units, improving assembly flexibility. The smooth sliding mechanism integrated into the guide frame helps in maintaining consistent performance even under frequent operational cycles.

GN19-12(C) indoor HV disconnect switch applies to power system of rated voltage 12kV, AC 50/60Hz. It is equipped with CS6-1 manual-operating mechanism and is used to break and make circuit under no-load. There are additional pollution type, high-altitude type and power indicating type. It is made as per IEC 62271-102. The isolating switch of this series is equipped with a CS6-1 manual operating mechanism (the isolating switch with a panel has its own conjoined operating mechanism).   This series of isolating switches is a three-pole type, which consists of a chassis, a rotating shaft, a lever, a porcelain pillar insulator, a knife and a wiring board. The rotating shaft is arranged on the bottom frame, on which three pairs of levers are welded, and the levers pass through the pull rod porcelain insulator and the knife necklace. The rotating shaft extends out of the base frame, and any section of the rotating shaft can be connected with the operating mechanism.   Type C is through the wall. Among them, C1 means that the rotation is on the side through the wall; C2 means that the disconnection is on the side through the wall; C3 means that both sides are on the side through the wall.

A Switchgear Drawer Microswitch is a vital component in the operation and safety of electrical switchgear systems. Designed for precision and reliability, this microswitch is typically installed within the switchgear drawer mechanism to detect and signal the position of the drawer—whether it is fully inserted, withdrawn, or in an intermediate position. The microswitch operates by actuating when the drawer moves, sending an electrical signal that can control various interlocking and safety functions.

Richge is a manufacturer of HV electrical sensor in China, specializing in producing advanced sensors designed to monitor and ensure the integrity of insulation in high-voltage electrical systems. Our insulation sensors are engineered to provide precise measurements and reliable performance, contributing to the safety and efficiency of high-voltage operations.
