Outdoor Circuit Breaker

ZW32-24 outdoor AC high-voltage vacuum circuit breaker (hereinafter referred to as circuit breaker) is rated voltage of 24kV, 50Hz three-phase AC outdoor power distribution equipment. This product is absorbing foreign advanced technology. Based on the dry domestic raw materials and factory art, the 24kV outdoor high-voltage switchgear suitable for China's national conditions has been successfully developed. Compared with similar international products, it has the characteristics of miniaturization, maintenance free and intellectualization. At the same time, the product has no pollution to the surrounding environment and is a green environmental protection product. The circuit breaker complies with technical standards such as gb1984-2003 high voltage AC circuit breaker, DL t402-2007 technical conditions for ordering high voltage AC circuit breaker and DL / t403-2000 technical conditions for ordering 12kV ~ 40.5kV high voltage vacuum circuit breaker .

The ZW7-40.5 outdoor high-voltage vacuum circuit breaker adopts a uniquely designed split pole and a highly reliable operating mechanism. The device is mainly used in medium-voltage overhead line power grids for dividing and combining load current, overload current, and short-circuit current.   ZW7-40.5 outdoor medium-voltage vacuum circuit breaker is athree-phase AC 50Hzoutdor high-voltage electrical equipment tis suitable for the control and protection of 20-40.5kV power transmission and distribution systems,it can also be used in the occasions of section circuit breakersand switched capacitor banks,this product can be used with piecewise controller,the reclosing device can realize intelligent sectioning and redosing control of the power system.A current transformer can be added for measurement and protection.The ring circuit breaker is equipped with a spring or electromagnetic actuator,with reliable mechanical performance and frequent operation;there is no riskof fire and explosion

ZW32-12 (FDGM) series outdoor high-voltage vacuum circuit breakers (hereinafter referred to as "circuit breakers") are outdoor distribution switchgear with a rated voltage of 12KV and three-phase AC 50Hz. Circuit breakers are mainly used for breaking and closing load current, overload current, and short circuit current in power lines. They have overload and short circuit protection functions, meet control and measurement requirements, and can also achieve remote control and monitoring functions. They are widely used in substations, industrial and mining enterprise distribution systems as control and operation purposes, especially suitable for places that require frequent operation. The circuit breaker complies with technical standards such as GB1984-2003, DL/T402-2007, and IEC60056.It is also used in rural power grid places with frequent operation for breaking and dlosing the load current and over load curent and short circuit current of power system，It is mainly used to break and close the load current, overload current and short circuit current in the power system. It is suitable for protection and control in substation and industrial and mining enterprise substation systems, and places where rural power grids operate frequently.

ZW32-40.5 series outdoor high-voltage vacuum circuit breakers are used in three-phase power systems with AC 50Hz and rated voltage of 35kV, as a means of separating and combining load current, overload current and short-circuit current. ZW32-40.5 outdoor high-voltage vacuum circuit breaker adopts a unique design of integrated sealed pole and high-reliability operating mechanism.The device is mainly used in medium voltage overhead power gird,as a sub-combined with load current,overload current and short circuit current.
