Vacuum Circuit Breaker Series

FKN12-12D/630-20 indoor AC high-voltage load switch is a three-phase high-voltage switchgear with a rated voltage of 12KV and a rated frequency of 50HZ. It is used for switching load current, closed-loop current, no-load transformer and cable charging current, off combined short-circuit current. The load switch equipped with the grounding switch can withstand short-circuit current.and m-ainly used in power distribution substation and industrial electrical equipment where three phase closed loop circuit or bottom power supply system for control and protection.

We are committed to developing Load Switch, Outdoor High Voltage Auto Recloser, Indoor Voltage Vacuum Breaker that are closer to the needs of consumers and provide consumers with better products. We always take rewarding society as a blessing and take the prosperity and revitalization of the motherland as our own responsibility. Our company takes our enterprise reputation and staff quality ahead of enterprise development as our development guarantee. We insist on the idea of science and technology is the first productive force. With our technical skils, efficient management and high-quality products, we have won praise from our customers with our cost-effective goods. LYL-12 series, suitable for three-phase AC 50Hz, with a rated voltage of 12kV, It features a rugged design, excellent arc extinguishing performance, and reliable operation under harsh grid conditions. LYL-12T load switch complies with the relevant requirements of GB3804-2004 "3.6kV~40.5kV high voltage AC load switch" and GB16926-1997 "AC high voltage load switch-fuse combination appliance". Main circuit: 630A-20kA (4s), 25kA (3s); Mechanical life: 5000 times; Grounding circuit: 20kA (2s); Mechanical life: 2000 times.

We are committed to developing Load Switch, Outdoor High Voltage Auto Recloser, Indoor Voltage Vacuum Breaker that are closer to the needs of consumers and provide consumers with better products. We always take rewarding society as a blessing and take the prosperity and revitalization of the motherland as our own responsibility. Our company takes our enterprise reputation and staff quality ahead of enterprise development as our development guarantee. We insist on the idea of science and technology is the first productive force. With our technical skils, efficient management and high-quality products, we have won praise from our customers with our cost-effective goods. FKRN-24D when load break switch equip with high voltage current limited fuse(with striker), it comes into being load break switch and fuse combination apparatus,acting as protecting and control apparatus for transformers, cable and overhead wiring. When a phase or multiphase fuse fusing, load break switch automatic brake three-phase. These series load break switch are especially applicable in rural,urban terminal substation and prefabricated substations, as well as ring network power supply.

FN7 series Load break switch, generally comes with the spring mechanism for switching oN & oFF the supply, however, option with vacuum circuit breaker is also available. Of course, option with Vacuum circuit breaker is costlier. Choice between these two totally depends on the customer. Load break switch with vacuum circuit breaker is more reliable option.FN7 36kv load break switch with fuse combination AC high voltage 。 The FN7-12DR type indoor AC high voltage load switch is is suitable for AC 50Hz, rated voltage 12kv three-phase AC power system as breaking any load current and short circuit current use, breaking up can be a combination of electrical short-circuit current , can be used as protection purposes.Richge is a leading manufacturer specializing in electrical switchgear components, with a focus on providing high-quality Switchgear Lower Hinges. Our products are crafted using premium materials and advanced manufacturing processes, ensuring exceptional durability and reliability in various industrial environments. With years of experience and technological innovation, our Switchgear Lower Hinges meet international standards, offering safe and stable support for customers worldwide. We are committed to continuously enhancing product performance, meeting diverse customer needs, and delivering exceptional service and solutions.

FN18 load switches and load switch-fuse combinations are high-voltage, high-performance load switches combining compressed-air arc extinguishing and gas-produced arc extinguishing. The combination of load switch and fuse combines the advantages of the load switch with those of the fuse to switch any load current up to the rated breaking current of the load switch, and to switch any overcurrent up to the rated short-circuit breaking current of the combination by means of the operation of the fuse and its impinger. It is used in three-phase power distributions of AC 50Hz rated voltage 12kv and rated current 630A Esp For power ring network in city net work construction improvement high-rise buildings and public facilities as an ideal product to protect package substation and transformer It has the features of advanced design simple operation impact structure smart appearance light weight complete function fast on-and off speed and high reliability.

FN18-D is a general purpose, three-pole, load break switch that offers switchgear owners and assemblers the advantages of an advanced interrupting technology and proven, dependable performance in a compact design. The switch is available to switchgear assemblers as a building block for metal-enclosed and pad-mounted switchgear applications in ratings from 12-40.5 kV. The standard FN18 switch includes a heavy-duty steel frame with stand-off insulators, a unique puffer-type arc extinguishing system, an operating mechanism and current-carrying components, including blade-type interrupters with cast hinges and jaw connectors. Optional accessories and features include a variety of operating handles, a motor operator, auxiliary switches, a shunt trip device, fuse bases, mechanical fuse tripping, grounding switches, mechanical door interlocking and key interlocking. FN18 series indoor high-voltage load switch has the advantages of easy design, operation, compact structure, small volume, full function, light weight, fast breaking and closing speed and high reliability. It is suitable for AC 50Hz, rated voltage 12kV, 24kV, rated current 630A and three-phase distribution system, especially for city network construction and renovation projects, high-rise buildings, ring network power supply of public facilities, and is an ideal product for box-type substation and transformer protection.

FKN12-12D series air-blast Ioad break switch and FKRN12-12D series air-blast load break switch-fuse combination apparatus are new series switchgear applies to three-phase electric distribution system of rated 12kV, acting as protecting and control apparatus for transformers, cable and overhead wiring. These series are especially applicable in rural, urban terminal substation and prefabricated substations, as well as ring network power supply. FKN12-12D can break and make Ioad current and over-current. FKRN12-12D can break and make over-current load current and short-circuit current(Iimited current fuse). This product is featured with impact structure aesthetic appearance. reliable interlock and high insulating level. In the spring storage operation mechanism, ON/OFF speed is free from the influence of the manpower. For the arc-extinguish, electric arc-extinguish inside the insulating cover, the free gas occurs at sparking do not cause descend of insulating level between phases and phase to earth. The insulation cover clapboard separates electrified part thus boost protection grade of ring main unit. The copper-tungsten contact and main contact brings along reliable conductivity and long life. This product achieves sound fame due to easy maintenance and operation as well as reliable performance. It is in compliance with IEC62271-105.

FZRN21 series Ac and HV indoor vacuum load break switch, this product has a breaking capacity, safety and reliability, long life, can operate freguent, compact structure, small size, light weight, the basic no need to maintain. FZN21-12 series high-voltage vacuum load switch is mainly composed of framer, disconnecting switch (current-limiting fuse of the combiner is in the disconnecting switch), vacuum switching tube, grounding switch, spring operating mechanism and so on. This product has compact structure, small volume, long life, strong closing and breaking capacity, and easy operation and maintenance. The vacuum switch is equipped with a spring-operated mechanism, which adopts an electric motor (another manual) spring energy storage, and there are two types of closing methods: electromagnet closing and manual splitting and closing. The disconnecting switch, vacuum switch and earthing switch are interlocked with each other (mechanical interlocking) to prevent misoperation. FZN21-12D/T630-20, FZN21-12DR/T125-31.5 type high-voltage vacuum load break switch and fuse switch are operating in three-phase AC electrical 12kV, 50Hz power distribution system, with a compact, small size, light weight, long service life, high making and breaking ability, safe and reliable, and if load switch cooperated with fuse namely fuse switch can replace those fuses with higher cost, easy and convenient operation and maintenance

Sulphur hexafluoride (SF6) is a good gas insulator. Its typical application is gas insulation in high-voltage switchgear of power supply systems. When the sulphur hexafluoride gas encounters high heat and high temperatures(e.g. arc), it produces hydrogen fluoride and sulphur dioxide gases, which coexist with undecomposed sulphur hexafluoride gases. The rated pressure of the SF6 high voltage circuit breaker is usually 0. 0.6 MPa(table pressure). The pressure of the SF6 gas must be checked against the temperature curve of the product when inflating or checking the temperature curve. FLN36-12kV SF6 load break switch is a switch equipment for medium voltage switchgear, using SF6 gas as arc extinguishing and insulating medium. There are three working positions: open, closed, earth position in the switch. The compact size, easy installation, and fine adaptability to environment make the switch suitable for many different applications.
