Product Details and Application of Support for Conductive Strip in Switchgear The Support for Conductive Strip in Switchgear is an essential component designed to provide reliable and secure mounting for conductive strips, which are crucial for effective electrical connectivity and performance in switchgear systems. Constructed from high-quality, durable materials such as stainless steel or corrosion-resistant alloys, these supports are engineered to withstand high temperatures and ensure longevity in demanding environments.

GN19-12(c) series indoor AC high voltage isolation switch is suitable for AC 50hz，rated working voltage of 12kv, 10kv, rated working current of 400A, 630A, 1250A power system, as a voltage and no load under the condition of breaking, closed circuit indoor switchgear.rated voltage 12kv and below power system, equipped with manual operation mechanism, used for switching electrical appliances under the condition of voltage but no load, There are also dispatched to produce anti-fouling type, plateau type and live display devices that can be installed. GN19-12 series indoor high voltage isolating switch is an indoor device with rated voltage of 12kv and three-phase AC 50hz.

SOLH VEX1 balanced poppet 3-way relief pressure regulator adopts poppet structure instead of traditional diaphragm design, delivering 3~5 times higher flow than standard AR regulators with oversized relief port for fast pressure relief and stable back pressure. It achieves superior regulation precision with hysteresis ≤0.03MPa, repeatability & sensitivity ≤0.01MPa. Two control modes are available: remote air pilot and integrated solenoid pilot for automatic multi-stage pressure switching. Max inlet pressure reaches 1.0MPa, with port sizes ranging from 1/8" to 2". Mountable at any angle and lubrication-free for dry oil-free air circuits; air pilot version works 0~60℃ while solenoid pilot variant ranges 0~50℃. Widely used for large air tank pressure stabilization & rapid relief, high-flow air blowing, large bore cylinder / air motor driving and multi-stage tension control systems for film & wire manufacturing.

The Switchgear Door Pin is a critical component designed for securing various elements within switchgear assemblies. Crafted from high-grade steel or stainless steel, this pin ensures durability and reliability in demanding electrical environments. The locking pin features a precision-engineered mechanism that guarantees a secure fit, preventing accidental disengagement or movement of switchgear components during operation.

SOLH HFZ linear guide parallel pneumatic gripper is directly interchangeable with SMC MHZ2 series. It adopts dual-piston rack & pinion synchronous transmission integrated with ball linear guide for high rigidity and excellent offset load resistance. Three actuation variants are available: standard double-acting HFZ; single-acting normally closed HFSZ (spring holds workpiece when air cuts off); single-acting normally open HFTZ (spring releases workpiece upon air loss). Bore sizes range from 6 to 40 mm with repeat positioning accuracy ±0.01~±0.02 mm. Multiple mounting options include bottom tapping, side mounting and through-hole N type. Dual-side sensor grooves and built-in magnetic rings support M9 series magnetic switches for open/closed feedback. Suitable for external clamping and internal expanding gripping. Optional accessories include dust covers, high-temperature seals and NSF-H1 food-grade grease. Effective clamping force decreases with extended jaw overhang; a safety factor ≥1.5 is required during load calculation. Widely deployed on robot end effectors, 3C electronics, precision hardware, injection molding and packaging automation precision gripping stations, especially for applications requiring power-off safety hold or release and working conditions with lateral offset loads.

Switchgear Door Lock Bent Plate – Product Details and Applications The Switchgear Door Lock Bent Plate is a critical mechanical component designed to enhance the safety and operational integrity of electrical switchgear systems. It serves as a key element in the door locking mechanism, ensuring the secure closure of switchgear cabinet doors. Typically made from robust materials such as stainless steel or zinc-coated metal, the bent plate offers durability, resistance to corrosion, and strength under mechanical stress, ideal for both indoor and outdoor switchgear installations. The bent plate features precise bends and dimensions to fit perfectly within the locking assembly, working seamlessly with handles, latches, or electromagnetic locks. It plays a crucial role in achieving smooth mechanical alignment between the door and frame, preventing accidental door openings caused by external vibrations or impact. Some variants are designed to support additional locking mechanisms, such as padlocks, to offer enhanced access control and security during maintenance or operation.
