SOLH VM4 (VM400) medium 3-port poppet mechanical valve is fully interchangeable with equivalent SMC models, positioned between mini VM1 and high-flow VM2 series. Its core advantage lies in compatibility with full pressure range from -100kPa vacuum to 1.0MPa positive pressure, a feature unavailable on VM2. It adopts standard Rc1/8 port with optional NPT/G1/8 threads and Cv=0.38 flow capacity, supporting side and bottom port piping layout. Built with solid metal body, it withstands 1000m/s² impact and heavy vibration, suitable for harsh heavy-duty production lines, with lubrication-free dust-resistant poppet sealing for long service life. A complete set of interchangeable actuators are provided: standard / hardened anti-abrasion steel roller lever, one-way anti-rebound roller, straight plunger, multi-color mushroom emergency stop buttons, 2/3-position rotary knobs, lockable pushbuttons and toggle hinge levers. Widely applied in cylinder & slide table stroke limit detection, vacuum adsorption/release circuits, equipment manual jog commissioning, machine safety emergency interlock and jig fixture switching, it is the ideal medium mechanical trigger valve for working conditions requiring vacuum compatibility and strong shock resistance.

Switchgear Limiting Block: Product Details and Applications The Switchgear Limiting Block is a crucial component designed to enhance the safety and efficiency of electrical switchgear systems. Constructed from high-grade insulating materials, it ensures durability and resistance to electrical stress, heat, and environmental factors. The limiting block is typically used in medium and high voltage switchgear to limit the movement of switchgear drawers, thereby preventing accidental disengagement during operation.

SOLH CJ1 ultra-miniature pin pneumatic cylinder is interchangeable with equivalent SMC models, offered in φ2.5 and φ4 bore sizes. φ2.5 is single acting spring return only, while φ4 supports both single acting and double acting versions. Slim and ultra-lightweight (2~3.5g), it features no built-in cushion for rapid response. The rod-side air port can be rotated ±90° to facilitate tubing layout. External threads on both ends enable direct axial fixing without extra brackets. It delivers thrust ranging from 0.64 to 6.3 N at 0.5 MPa, suitable for micro loads below 100 g to avoid impact damage to delicate tiny workpieces. NBR seals support oil-free operation for clean environment. Widely applied in short-stroke high-frequency push-pull tasks including 3C button durability testing, chip ejection, micro component positioning, precision instrument fine-tuning and miniature actuators for medical devices. A thrust safety factor of at least 50% is recommended during selection.

SOLH VP series CE certified pilot large-size 3-port solenoid valve features ultra-high flow with port sizes from Rc 3/8" to 1-1/2" and max Cv up to 7.0. Three grades of energy-saving coils (1.55W/0.55W/0.4W) are optional, with switchable NC/NO function without pipe modification, supporting 0~1.0MPa positive pressure and -101.2kPa vacuum conditions. Equipped with ozone-resistant HNBR main seals, FKM pilot seals and built-in dust filter, it allows arbitrary mounting and delivers a 50-million-cycle service life. Perfectly matched with VBA boosters and VBAT air tanks, it also fits heavy cylinders, vacuum fixtures, electrical cabinets, automotive & packaging machinery. Certified with CE, ASME, GB and ISO9001, it is an ideal heavy-duty switching valve for industrial pneumatic boosting and automation systems.

Richge specializes in high-quality low voltage pin connectors designed to meet the demands of modern electrical systems. We offer a range of connectors known for their reliability, precision, and durability. Our products feature advanced materials and engineering to ensure secure and efficient electrical connections in various applications, including automotive, industrial, and consumer electronics. With a commitment to innovation and customer satisfaction, we provide solutions that enhance performance and safety in low voltage environments.

Switchgear Spring Clamp Bolt: Product Details and Applications The Switchgear Spring Clamp Bolt is an essential component designed for securing various elements within switchgear systems. Crafted from high-grade materials, this bolt offers exceptional durability and resistance to corrosion, ensuring reliable performance in demanding environments. Its spring mechanism allows for a flexible yet firm grip, accommodating slight variations in alignment and maintaining stability under dynamic loads.
