Product Details and Application of Switchgear Head Form Spring Clamp The Switchgear Head Form Spring Clamp is a pivotal component designed for securing and stabilizing electrical connections within switchgear systems. Constructed from high-grade stainless steel, this clamp boasts exceptional durability and resistance to corrosion, ensuring long-lasting performance even in harsh environments. Its innovative head form design facilitates easy installation and removal, allowing for quick maintenance and adjustments without compromising the integrity of the electrical connections.

VBI-12 medium voltage vacuum circuit breaker is a kind of indoor medium voltage switch equipment with 50Hz/60Hz three phase AC 12kV rated. voltageVBI type vacuum circuit breaker conforms to national standard GB1984-2003 HV Vacuum Circuit Breaker, JB3855-1996<3.6-40.5kV indoor AC high voltage vacuum circuit breaker>, DL/T403-2000<12kv-40.5kv HV vacuum circuit breaker ordering technical conditions>, and IEC62271-100:2001 high voltage AC circuit breaker relevant regulations.VBI high voltage vacuum circuit breaker is used for 12kv or 24kv power system indoor switching ecuipment

VBI-24 medium voltage vacuum circuit breaker is a kind of indoor medium voltage switch equipment with 50Hz/60Hz three phase AC 24kV rated voltage, which combined the technology of the ABB corporation in Switzerland and developed in China. Product complies with the standard GB1984 & IEC62271-100. VBI-24VCB usually mounted into switchgear panel KYN28 and XGN. It is applicable in occasions with frequent operation, has functions of high-speed recloser, Multiple Opening/Closing, reliable mechanical interlock. It has fixed type & withdrawable type. It adopts the composite insulated material, there is no pollution and explosion danger, the insulation level is high. VBI-24 indoor medium-voltage sealed vacuum circuit breaker is suitable for air-insulated indoor switches and is used for control and protection in power grids with AC and rated voltage of 24KV and below. Vacuum circuit breakers are used in frequent It has extremely excellent performance in operation and situations where the circuit breaker current needs to be opened, fully meets the requirements of automatic closing, and has high reliable operation and service life.

Product Details and Application of Switchgear Aluminum Guide Rail The Switchgear Aluminum Guide Rail is a critical component designed for the efficient operation and support of switchgear systems. Constructed from high-quality aluminum, this guide rail offers exceptional strength while remaining lightweight, facilitating easy installation and maintenance. Its corrosion-resistant properties ensure durability, making it suitable for various environments, including industrial settings and outdoor applications.

GN19-12 Indoor High Voltage Disconnect Switch GN19-12 series indoor high voltage disconnect switch belong to high voltage switch equipments, applies to power system of rated voltage 12KV, AC 50Hz and less than it system, it is equipped with CS6-1 manual operating mechanism and is used to break and make circuit under no-load but with voltage. There are additional pollution abatement type, high altitude type and electrified display. The role of the disconnect switch is to disconnect the circuit without load current. So that the equipment to be serviced and the power supply has a clear disconnection point to ensure the safety of maintenance personnel, isolation switch without special interrupting device can not cut off the load current and short-circuit current, so the circuit must be in the circuit breaker to break the circuit before you can operate the isolation switch.

SOLH MSQ rack-and-pinion rotary actuator is fully interchangeable with equivalent SMC rotary tables. Driven by symmetrical dual piston gear rack structure, it generates 3~4 times higher torque and superior radial & axial load capacity versus vane-type CRQ cylinders. Two grades are available: MSQB standard series with H9 tolerance and MSQA high-precision series featuring H8 fit and ±0.01mm repeat positioning accuracy. The rotary table is pre-machined with locating pin holes and fixture tapping holes, plus a central hollow through hole for wiring & tubing routing. Equipped with dual-end angle adjustment screws for infinitely adjustable swing range 0~190°, fixed 90°/180° swing variants are optional. Two damping solutions are offered: standard rubber bumpers and suffix-R integrated hydraulic shock absorbers (L low kinetic energy / H high kinetic energy). Dual piping layouts include default end-face ports and E side front ports. Built-in magnetic rings support M9BW reed switches to transmit position feedback signals to PLC. Frame sizes range from 10 to 200, pre-filled with long-life grease for lubrication-free operation. Widely applied to PCB optical inspection, microchip precision positioning, packaging direction switching, machine tool workpiece flipping and mini manipulator end rotary joints for indexing, turnover and multi-angle positioning automation.
