China pilot operated solvent fluid valve Manufacturer, Supplier, Factory

Switchgear Secondary Installation: Product Details and Applications Product Overview Switchgear secondary installation refers to the configuration, interconnection, and installation of secondary circuits and components within a switchgear system. Secondary circuits manage control, protection, metering, and signaling functions, ensuring efficient and safe electrical distribution. These installations typically involve control cables, auxiliary relays, secondary terminals, wiring looms, sensors, and protective devices like current transformers (CTs) and voltage transformers (VTs). They complement the primary system, facilitating effective monitoring and control over medium and low-voltage networks.

Drawer operating mechanism for switchgear Product Details and Application of Switchgear Drawer Operating Mechanism The switchgear drawer operating mechanism is an essential component designed to enhance the functionality and safety of electrical distribution systems. This mechanism allows for the smooth operation of switchgear drawers, facilitating the insertion and withdrawal of electrical devices while ensuring reliable connections and disconnections.

VSG-12 type Indoor high voltage vacuum circuit breaker used spring to storage energy. The operating mechanism can be operated by two ways, by manual and electromotive operation, The characteristics is according with GB1984-2003 High Voltage AC Circuit Breaker, JB3855-1996 3.6-4.5KV Indoor AC High Voltage AC Circuit Breaker and IEC standard 62271-100:200162271-100:2001 High Voltage AC Circuit Breaker VSG type indoor high-voltage vacuum circuit breaker is suitable for switching various loads of different natures and frequent operations in power systems with three-phase AC 50Hz and rated voltage of 7.2kV-40.5kV. It can be used in industries, mining, enterprises, and power plants. And for the protection and control of electrical equipment in substations. It can be equipped with KYN28A and other mid-mounted handcart switch cabinets, and can also be equipped with XGN fixed switch cabinets. The VSG indoor high-voltage vacuum circuit breaker complies with the national standards GB1984 “AC High-voltage Circuit Breaker”, JB/T3855 “3.6~40.5kV Indoor AC High-voltage Vacuum Circuit Breaker” and IEC60056 “High-Voltage AC Circuit Breaker” standards.

SOLH CP96S tie rod profile cylinder complies with ISO15552 and VDMA24562 standards, fully interchangeable with original CP96S series. Designed with dual buffer system combining adjustable air cushion and rubber pad, it achieves low noise and mild impact under high-speed & high-frequency reciprocation at 50~1000mm/s. The built-in tie-rod aluminum barrel is 15% lighter than conventional tie rod cylinders with high rigidity and excellent offset load resistance. Variants include single rod standard type and CP96SD anti-torsion double rod model. Built-in magnetic ring optional for M9B/A93 sensors; high temperature and stainless steel piston rod versions available. Bore φ32~125mm, customized stroke up to 2000mm. Widely used on machine tools and heavy-duty packaging automation for global equipment replacement.

At Richge, we specialize in high-quality switchgear components, including our robust Switchgear Drawer Locks. Designed for reliability and security, our drawer locks ensure safe and efficient operation within switchgear systems. Engineered with precision, they offer exceptional durability and a secure locking mechanism to protect critical electrical components. Our commitment to innovation and quality means that each lock undergoes rigorous testing to meet industry standards. We cater to various industrial needs, providing tailored solutions that enhance safety and performance. Partner with us for dependable switchgear solutions that stand the test of time.

SOLH TN cost-effective twin shaft cylinder adopts a single-piston dual guide shaft structure with slide bearing guidance for compact layout and excellent cost performance. It comes factory-equipped with built-in magnetic rings and an adjustable front rubber buffer for stroke fine tuning, delivering anti-rotation accuracy of ±0.2°. Synchronized dual shafts restrain torsion and swing to bear slight lateral eccentric loads. Three-direction mounting (top, bottom, side) is available, and side grooves support direct installation of magnetic switches without extra brackets. Two types are supplied: standard single-end rod TN and double through rod TNW, with TNW allowing fixture assembly on both rod ends for bidirectional synchronous centering motion. Compared with TR series, TN features smaller dimensions and lower cost without φ6 bore option; compared with CXS/CXSJ dual-piston twin cylinders, TN outputs single thrust with obvious cost advantages yet lower precision and load capacity. Its working pressure ranges from 0.15 to 1.0 MPa and ambient temperature adaptability covers −20℃~70℃. It is widely used for light-load positioning, simple pressing, workpiece stopping and short-distance transfer for general automation stations with moderate precision requirements and cost control demands. The S-type magnetic ring is standard for the whole series and cannot be removed; default Rc thread can be customized to G thread or NPT thread for overseas projects.
