China CT68-24 Vacuum Breaker Manufacturer, Supplier, Factory

The AC Ground Switch for Switchgear is an essential safety device in high-voltage power systems, providing a secure means to ground and isolate electrical equipment during maintenance activities. Operating within voltage ranges of 12kV to 40.5kV, it features outstanding short-circuit current resistance and reliable mechanical functionality. Its compact design facilitates easy installation and flexible operation, making it suitable for various high-voltage switchgear applications and substations. Built to meet rigorous international standards, this grounding switch ensures consistent safety and reliability in demanding electrical settings.

Product Details and Application of Switchgear Secondary Plug-In The Switchgear Secondary Plug-In is a crucial component designed to facilitate secure, reliable, and easy electrical connections within switchgear assemblies. Made from high-quality, durable materials such as copper, aluminum, and thermoplastic insulating compounds, this plug-in is engineered to meet stringent safety standards and provide excellent electrical conductivity. It is primarily used in low to medium voltage switchgear systems, providing a secure interface for secondary electrical circuits, control circuits, and auxiliary functions.

ZW32-12 (FDGM) series outdoor high-voltage vacuum circuit breakers (hereinafter referred to as "circuit breakers") are outdoor distribution switchgear with a rated voltage of 12KV and three-phase AC 50Hz. Circuit breakers are mainly used for breaking and closing load current, overload current, and short circuit current in power lines. They have overload and short circuit protection functions, meet control and measurement requirements, and can also achieve remote control and monitoring functions. They are widely used in substations, industrial and mining enterprise distribution systems as control and operation purposes, especially suitable for places that require frequent operation. The circuit breaker complies with technical standards such as GB1984-2003, DL/T402-2007, and IEC60056.It is also used in rural power grid places with frequent operation for breaking and dlosing the load current and over load curent and short circuit current of power system，It is mainly used to break and close the load current, overload current and short circuit current in the power system. It is suitable for protection and control in substation and industrial and mining enterprise substation systems, and places where rural power grids operate frequently.

Their compact dimensions and limited weights make the Power Cube type PB/F fixed parts the ideal solution for replacing fixed circuit breakers with withdrawabie circuit breakers, for retrofitting activities and for upgrading obsolete switchgear to the new Standards. The Power Cube type PB/F fixed parts are factory-assembled and tested and, where applicable, comply with IEC 62271-200 and IEC 62271-1 Standards. The fixed parts allow construction of arc proof switchgear - classification LSC2B-PM IAC BFLR or LSC2B-PM AFLR according to IEC 62271-200 (in accordance with IEC 62271 Standards for general characteristics).

GN19-12 Indoor High Voltage Disconnect Switch GN19-12 series indoor high voltage disconnect switch belong to high voltage switch equipments, applies to power system of rated voltage 12KV, AC 50Hz and less than it system, it is equipped with CS6-1 manual operating mechanism and is used to break and make circuit under no-load but with voltage. There are additional pollution abatement type, high altitude type and electrified display. The role of the disconnect switch is to disconnect the circuit without load current. So that the equipment to be serviced and the power supply has a clear disconnection point to ensure the safety of maintenance personnel, isolation switch without special interrupting device can not cut off the load current and short-circuit current, so the circuit must be in the circuit breaker to break the circuit before you can operate the isolation switch.

The chassis lock plate is a critical component used in electrical systems to securely fasten and lock the chassis of switchgear or electrical panels in place. Designed for safety and stability, this plate ensures that the chassis remains securely positioned during installation, maintenance, or operation, preventing accidental movement and enhancing the overall reliability of the electrical equipment. Made from high-strength materials, the chassis lock plate is built to withstand the rigors of industrial environments and provide long-lasting performance. It is easy to install and can be integrated into various switchgear configurations, offering flexibility and compatibility with different types of equipment. Ideal for use in substations, control rooms, and industrial facilities, the chassis lock plate plays an essential role in protecting both personnel and equipment. Compliant with international safety standards, it offers peace of mind by ensuring the secure operation of electrical systems.
