GN19-12(c) series indoor AC high voltage isolation switch is suitable for AC 50hz, rated voltage 12kv and below power system,It is equipped with CS6-1 manual-operating mechanism and is used to break and make circuit under no-load. There are additional pollution type, high-altitude type and power indicating type. It is made as per IEC 62271-102. used for switching electrical appliances under the condition of voltage but no load, There are also dispatched to produce anti-fouling type, plateau type and live display devices that can be installed. GN19-12 series indoor high voltage isolating switch is an indoor device with rated voltage of 12kv and three-phase AC 50hz.

The VS1-12/4000-275 vacuum circuit breaker is a high-performance medium-voltage switchgear component, engineered for demanding industrial and distribution applications requiring reliability, efficiency, and superior safety. This model is designed with a draw-out, making installation and maintenance easy and convenient, and it fits a variety of switchgear configurations. VS1-12 type vacuum circuit breaker is a kind of indoor high voltage switch device which is used in the AC Three-phase power system of frequency 50HZ,rated voltage 12KV to be the protection and control unit.  Because of the special superiority of vacuum circuit breaker, especially suitable for applications that require frequent operation at rated operating Current or multiple open short-circuit breaking current location. It 1s especially suitable to the place requiring frequent operations.

The Switchgear Door Cover is an essential component designed to protect the switchgear equipment from environmental factors and physical damage. Crafted from high-quality, durable materials such as impact-resistant fiberglass or steel, this door cover ensures robust protection and longevity. Its design incorporates a secure locking mechanism to prevent unauthorized access, while also allowing for easy operation and maintenance. The cover is engineered to withstand high voltages and extreme conditions, providing a crucial barrier against dust, moisture, and accidental contact.

SOLH VM2 (VM200) medium mechanical poppet valve is fully interchangeable with matching SMC models. Featuring medium poppet construction with Cv=0.87 flow coefficient, its flow capacity is around 8 times higher than mini VM1 series, equipped with standard Rc1/4 port and optional NPT/G1/4 threads. It works under 0~1.0MPa and is incompatible with vacuum, adopting lubrication-free wear-resistant poppet seal and robust metal body. Side port and bottom port piping layouts are available, supported by a complete lineup of interchangeable actuators: standard POM roller / hardened steel abrasion-resistant roller lever, one-way anti-rebound roller, straight plunger, flat pushbutton, yellow mushroom emergency stop head, green indicator button and lockable hinge knob. The hardened steel roller variant fits heavy-duty high-wear production lines. Widely used for cylinder & slide table stroke limit detection, equipment manual jog commissioning, jig fixture air switching and safety emergency interlock, it serves as the mainstream mechanical air trigger valve for packaging, textile, printing and general automation production lines.

SOLH 4A series 5/2-way and 5/3-way air-operated directional control valves are the full pneumatic counterpart of the classic 4V electromagnetic solenoid valve series. Driven entirely by external pneumatic control signals with no coils or electrical parts inside, this valve achieves inherent explosion-proof safety and serves as the core control unit for non-electric pneumatic loops, hazardous explosive areas and safety interlock systems. It adopts high-precision spool configuration and robust aluminum alloy housings, sharing identical installation dimensions and flow characteristics with the 4V series for seamless direct replacement and upgrade between electric-driven and full-pneumatic control schemes. The standard five-port layout follows industry universal specifications: P for main air supply inlet, A and B as working ports connected to two chambers of double-acting cylinders for extension and retraction regulation, R and S as exhaust ports compatible with standard silencers to reduce operational noise. The 5/2-way lineup supplies single pneumatic control and double pneumatic control options. Single air-controlled models switch upon receiving control air signals and automatically reset by built-in springs once the control pressure disappears to deliver fail-safe protection. Double air-controlled variants feature no return springs and lock the current spool position persistently after control air is disconnected, supporting long-duration positioning and pressure retention without sustained control air input. 5/3-way versions are exclusively double air-driven with three selectable neutral configurations: closed center (Type C) seals all ports to lock cylinders and prevent vertical falling; exhaust center (Type E) vents A/B ports to atmosphere for pressure release and manual commissioning; pressure center (Type P) feeds compressed air to both working ports for synchronous clamping and force balance adjustment. Suitable for filtered compressed air within 0.15~0.8 MPa working pressure, the whole series supports lubrication-free operation and works reliably from -20℃ to +70℃. Widely applied in chemical plants, painting workshops, mining and other explosion-risk environments, it cooperates with mechanical valves, hand-operated valves and air pilot valves to build complete all-pneumatic logic control systems for double-acting cylinders.

SOLH MD multi-position free-mount compact cylinder is equipped with tapped mounting holes on six sides of the block body for bracket-free installation at any angle, 30%~50% thinner than standard round cylinders to fit narrow, high-density equipment layout. Five sub-models cover all working modes: standard single-rod double acting MD, single-rod single acting MSD (spring extend) / MTD (spring retract), anti-torsion double-rod MDD, and stroke-adjustable double-rod MDJ. Bore sizes range from 6 to 32 mm with standard strokes 5~60 mm. Each unit comes with built-in front rubber buffer and dual side slots for magnetic sensors; suffix-S stands for integrated permanent magnet compatible with CMSH/DMSH reed switches. The piston rod adopts integrated self-lubricating bushing for oil-free smooth operation. Double-rod variants eliminate lateral deflection from offset loads, while MDJ features rear adjustment screw for flexible stroke fine-tuning. Widely applied to light-duty clamping, ejecting, crimping and precise positioning of miniature jigs in 3C, semiconductor and general small automation machinery.
