Product Introduction: Switchgear Main Circuit Connector The Switchgear Main Circuit Connector is a crucial component designed for seamless electrical connections in medium and low-voltage switchgear systems. These connectors ensure the efficient transmission of electrical power between various switchgear components, such as circuit breakers, transformers, and busbars, ensuring reliable operation in critical electrical infrastructure.

VBI-12 medium voltage vacuum circuit breaker is a kind of indoor medium voltage switch equipment with 50Hz/60Hz three phase AC 12kV rated. voltageVBI type vacuum circuit breaker conforms to national standard GB1984-2003 HV Vacuum Circuit Breaker, JB3855-1996<3.6-40.5kV indoor AC high voltage vacuum circuit breaker>, DL/T403-2000<12kv-40.5kv HV vacuum circuit breaker ordering technical conditions>, and IEC62271-100:2001 high voltage AC circuit breaker relevant regulations.VBI high voltage vacuum circuit breaker is used for 12kv or 24kv power system indoor switching ecuipment

Richge excels in providing high-quality Drawout Switchgear Auxiliary Contact Jacks, designed to enhance the functionality and reliability of switchgear systems. These jacks ensure secure connections for auxiliary contacts, supporting seamless integration and operation within drawout switchgear assemblies. Crafted from durable materials with precision engineering, our jacks offer easy installation, robust performance, and long-term reliability. Ideal for industrial and commercial applications, they meet rigorous industry standards, ensuring optimal safety and efficiency. Choose our Drawout Switchgear Auxiliary Contact Jacks for dependable performance and superior quality in your switchgear solutions.

The VSM-12 vacuum circuit breaker integrates a permanent magnet operating mechanism and a vacuum interrupter in a front-and-rear configuration. The breaker features a draw-out type design with a fixed arc-extinguishing column (solid sealing poles) and is designed for high reliability and performance in demanding electrical environments. The permanent magnet operating mechanism and the vacuum interrupter of the VSM-12M vacuum circuit breaker adopt front and rear arrangement. The main conductive circuit is a floor-standing structure. The upper and lower outlet seats and the vacuum interrupter are installed in an embedded pole Inside. The embedded pole is made of epoxy resin by APG process. This structure can prevent dust accumulation on the surface of the vacuum arcing chamber and prevent it from being damaged by external factors. It can ensure that the product still has good insulation performance in the humid and hot environment and serious pollution.

Product Introduction: Guide Frame Assembly for Switchgear The Guide Frame Assembly for Switchgear is an essential structural component that ensures the smooth and precise operation of switchgear drawers and compartments. This assembly is designed to align, guide, and secure the moving parts of switchgear systems, particularly in withdrawable units. It provides stability during insertion and withdrawal of circuit breakers or other functional modules, minimizing operational risks such as misalignment or mechanical jamming. Manufactured from high-grade materials such as stainless steel or galvanized metal, the frame offers exceptional resistance to corrosion and mechanical wear, which extends the lifespan of the switchgear. Some assemblies feature pre-drilled holes or adjustment slots to accommodate easy installation and fine-tuning. This ensures compatibility with various switchgear brands and modular units, improving assembly flexibility. The smooth sliding mechanism integrated into the guide frame helps in maintaining consistent performance even under frequent operational cycles.

Switchgear rollover control panel frame At Richge, we deliver top-quality switchgear solutions, including our advanced rollover control panel frames. Designed for durability and ease of use, our frames ensure optimal support and protection for switchgear systems. Engineered with precision, they enhance safety and operational efficiency, meeting the highest industry standards. Trust us for reliable, high-performance switchgear components.
