China tank pressure control regulator Manufacturer, Supplier, Factory

SOLH MHY2 cam-driven 180° wide swing pneumatic gripper is fully interchangeable with equivalent SMC models. It adopts cam transmission instead of gear mechanism, achieving maximum 180° opening angle with -3° over-close position to prevent workpiece loosening. Bore sizes cover 10/16/20/25 mm, purely double acting without single acting NO/NC variants, and repeat positioning accuracy reaches ±0.02 mm. Optimized narrow clearance construction enhances dust resistance. Four-side sensor grooves are available, and through-hole mounting is optional. Built-in magnetic rings work with M9 series reed switches to send open/closed feedback signals to PLC. Due to lever transmission, effective clamping force declines sharply with extended jaw overhang; torque verification is required during selection, and clamping arm length is recommended within 35 mm. Ideal for picking and flipping large-diameter tubular and irregular workpieces at miniature robot end effectors. MHW2 gear swing gripper is recommended if power-off holding or larger heavy-duty bore is required; MHZ2 parallel gripper is preferred for centered linear clamping.

SOLH CRBU2 ultra-thin free-mount vane rotary actuator is fully interchangeable with equivalent SMC models, available in bore sizes 10/15/20/30/40. Integrated cylindrical body enables bracket-free multi-directional fixing, 12% lighter than CRB2 series, perfect for concealed installation inside compact integrated machinery. Direct vane drive eliminates gear backlash with ultra-high angular repeatability of ±0.01°. Two vane variants: S single vane for max 270° swing, D double vane delivering double torque with limited 90°/100° rotation. Dual piping layouts are offered: standard side ports and suffix-E central axial ports. Optional suffix-W angle adjuster realizes infinitely adjustable stroke from 0 to 240°, and built-in magnetic rings support M9BW reed switches for PLC limit feedback. Low-friction composite sealing ensures oil-free operation with over 5 million service cycles. Widely applied to light-load high-frequency precision rotation tasks including 3C miniature jig turnover, vision camera positioning, screw tightening mechanisms and small-angle packaging switching. Compared with base-mounted CRB2 rotary cylinders, CRBU2 requires no mounting brackets and maximizes space efficiency, ideal for robot end effectors and narrow internal equipment layouts.

Richge specializes in the design and manufacturing of electrical switchgear mechanisms, providing high-quality and reliable solutions to customers worldwide. Our product range includes various switchgear mechanisms such as operating mechanisms, interlocking devices, and safety locks, widely used in power systems and industrial facilities. With advanced technology and extensive industry experience, we ensure that each product meets international standards and caters to specific customer needs. Our goal is to become a leading supplier of electrical switchgear mechanisms through continuous innovation and exceptional customer service.

At Richge, we specialize in high-quality switchgear front panel screws designed to ensure durability and reliability in electrical systems. Our screws are crafted from premium materials, offering exceptional strength and resistance to environmental factors. Ideal for securing front panels in switchgear assemblies, our products are engineered to meet stringent industry standards and provide a secure, long-lasting fit. With a focus on precision and performance, we deliver solutions that enhance the integrity and functionality of your switchgear installations. Trust Richge for innovative, reliable fastening solutions that support the efficiency and safety of your electrical infrastructure.

The Switchgear Guide Rail is a crucial component in electrical switchgear systems, designed to ensure the smooth and reliable operation of various switchgear parts. Constructed from high-strength, corrosion-resistant materials such as stainless steel or galvanized steel, these guide rails provide exceptional durability and stability under demanding conditions.

The Switchgear Panel Connection Kit is an essential component designed to facilitate the seamless integration of switchgear panels in various electrical systems. This kit includes a comprehensive set of connection components such as terminal blocks, mounting brackets, and high-quality connectors that ensure reliable and efficient panel assembly and connection.
