China large allowable torque guide cylinder Manufacturer, Supplier, Factory

Richge specializes in high-quality switchgear drawer mechanical interlocking solutions. Our designed mechanical interlocking systems are aimed at enhancing the safety and reliability of switchgear operations. These interlocking devices effectively prevent incorrect operations and ensure equipment functions correctly in its designated position. Our technology combines advanced engineering design with rigorous quality control, ensuring durability and stability of the interlocking systems. We are committed to providing customized solutions to meet diverse application needs. Choose us for efficient and secure switchgear management solutions.

ZW32-12 (FDGM) series outdoor high-voltage vacuum circuit breakers (hereinafter referred to as "circuit breakers") are outdoor distribution switchgear with a rated voltage of 12KV and three-phase AC 50Hz. Circuit breakers are mainly used for breaking and closing load current, overload current, and short circuit current in power lines. They have overload and short circuit protection functions, meet control and measurement requirements, and can also achieve remote control and monitoring functions. They are widely used in substations, industrial and mining enterprise distribution systems as control and operation purposes, especially suitable for places that require frequent operation. The circuit breaker complies with technical standards such as GB1984-2003, DL/T402-2007, and IEC60056.It is also used in rural power grid places with frequent operation for breaking and dlosing the load current and over load curent and short circuit current of power system，It is mainly used to break and close the load current, overload current and short circuit current in the power system. It is suitable for protection and control in substation and industrial and mining enterprise substation systems, and places where rural power grids operate frequently.

Richge specializes in the development and manufacturing of high-performance Vertical Busbar Systems, dedicated to providing reliable and efficient solutions for power distribution. Our vertical busbar systems are compactly designed and easy to install, making them ideal for a wide range of industrial and commercial environments. Utilizing premium conductive materials and advanced manufacturing processes, we ensure that our products deliver exceptional stability and safety in high-current applications. We are committed to continuous innovation, offering our customers more flexible and efficient power management system solutions.

SOLH CXSJ is an upgraded ultra-compact iteration of classic CXS twin cylinders, interchangeable with original SMC CXS series. Built with integrated dual pistons and dual guide rods, it delivers doubled thrust at the same bore size with stable anti-rotation accuracy of ±0.1°. Its overall dimensions are shortened and narrowed by 10%~20% with lighter weight, tailor-made for extremely narrow internal equipment layout. Four sub-models are available: CXSJM with slide bearing features excellent wear resistance and dust-proof performance for low-speed general positioning; CXSJL ball bearing type boasts ultra-low friction and smooth movement with a maximum speed of 800 mm/s for high-frequency high-speed pick-and-place; CXSJWM/CXSJWL double through rod designs enable workpiece installation on both ends for bilateral synchronous lifting and centering positioning. φ6 and φ10 bores support both axial and side porting while other sizes adopt side piping only. The reversible magnetic switch bracket supports 4-direction interference-free assembly and symmetrical left-right installation. Dual-end rubber buffers come as standard; suffix Z stands for built-in magnetic rings for position sensors, and non-magnetic versions are available for anti-magnetic-interference scenarios. Optional extension lock P and retraction lock R can hold the actuator steadily at designated positions. It is widely used for pick-and-place, light pressing and precision limiting positioning under light loads within compact automation equipment for 3C and general production lines.

Our company offers high-quality electrical switchgear observation windows designed to enhance visibility and safety in switchgear systems. These windows provide a clear view of internal components, allowing for easy monitoring and quick assessments without the need for direct access. Made from durable, impact-resistant materials, our observation windows are engineered to withstand harsh environments while maintaining clarity and reliability. We focus on precision and quality to ensure our products meet the highest industry standards, helping our clients maintain safe and efficient electrical operations.

The 8PT Guiding Part is an essential component in switchgear systems, designed to provide precise alignment and smooth operation of moving elements within the switchgear assembly. This guiding part plays a crucial role in ensuring the accurate positioning and secure movement of drawers, circuit breakers, and other mobile parts, enhancing the overall reliability and safety of the electrical distribution system.
