Switchgear Copper Connector Bar – Product Details and Applications The Switchgear Copper Connector Bar is a critical component used in electrical switchgear systems, ensuring the efficient and reliable flow of electrical current between different conductors. Made from high-quality copper, this connector bar offers superior electrical conductivity and low resistivity, minimizing energy loss during power transmission. The copper material also provides excellent thermal performance, which is crucial for high-current applications. Additionally, the connector bar is often coated with a protective layer such as tin or silver plating to enhance corrosion resistance, ensuring long-term durability in harsh operating environments. These bars come in various shapes and dimensions, including flat bars, U-shaped, and T-shaped designs, to accommodate different connection needs in switchgear panels. They are customizable to match specific system layouts, with pre-drilled holes or slots for easy mounting. Some models may feature insulation covers to enhance safety, especially in medium- and high-voltage switchgear systems.

Richge specializes in providing high-quality Switchgear 4P Jaw Support solutions for switchgear. Our 4P jaw supports are designed to stabilize and support the four-pole contact points in switchgear, ensuring reliable electrical connections and performance. Made from premium materials, these supports offer excellent durability and wear resistance. Each product undergoes rigorous testing to meet international standards, making them suitable for various industrial and commercial applications. Choose our 4P jaw supports for superior product quality and exceptional service support.

The Switchgear Locking Key is an essential safety component designed for secure operation and maintenance of electrical switchgear systems. Crafted from high-strength, corrosion-resistant materials, this key ensures reliable locking and unlocking of switchgear enclosures, safeguarding against unauthorized access and accidental operation.

The Switchgear Door Pin is a critical component designed for securing various elements within switchgear assemblies. Crafted from high-grade steel or stainless steel, this pin ensures durability and reliability in demanding electrical environments. The locking pin features a precision-engineered mechanism that guarantees a secure fit, preventing accidental disengagement or movement of switchgear components during operation.

FN18-D is a general purpose, three-pole, load break switch that offers switchgear owners and assemblers the advantages of an advanced interrupting technology and proven, dependable performance in a compact design. The switch is available to switchgear assemblers as a building block for metal-enclosed and pad-mounted switchgear applications in ratings from 12-40.5 kV. The standard FN18 switch includes a heavy-duty steel frame with stand-off insulators, a unique puffer-type arc extinguishing system, an operating mechanism and current-carrying components, including blade-type interrupters with cast hinges and jaw connectors. Optional accessories and features include a variety of operating handles, a motor operator, auxiliary switches, a shunt trip device, fuse bases, mechanical fuse tripping, grounding switches, mechanical door interlocking and key interlocking. FN18 series indoor high-voltage load switch has the advantages of easy design, operation, compact structure, small volume, full function, light weight, fast breaking and closing speed and high reliability. It is suitable for AC 50Hz, rated voltage 12kV, 24kV, rated current 630A and three-phase distribution system, especially for city network construction and renovation projects, high-rise buildings, ring network power supply of public facilities, and is an ideal product for box-type substation and transformer protection.

The Switchgear Drawer Hinge is a critical component designed for the seamless operation and durability of switchgear panels. Constructed from high-grade materials such as stainless steel or durable alloys, these hinges are engineered to withstand harsh environmental conditions and heavy-duty usage. The precise engineering ensures smooth panel movement, offering both robustness and reliability.
