Energy Saving Compact Booster Regulator (VBA Series) | SOLH by Richge Technology

Brand: SOLH by Richge Technology (睿其格科技)

Product Alias: VBA Pneumatic Pressure Booster / Pressure Intensifier / Air Pressure Increasing Valve

Overview

     The SOLH compact energy-saving booster regulator is a high-efficiency pneumatic pressure intensifier designed for local air pressure compensation and pressure amplification. Adopting optimized pneumatic boosting structure and miniaturized layout, it stably boosts standard workshop air pressure without modifying the main air compressor system. Compared with traditional booster valves, this unit features lower air consumption, smaller footprint and more stable pressure output, perfectly suited for compact automation equipment and high-precision clamping scenarios.

Core Key Features

1. High Energy-Saving Performance

     Optimized internal air circuit and one-way pressure-locking structure effectively reduce invalid air discharge. It cuts air consumption during long-term pressure holding, greatly lowering equipment operating cost compared with conventional booster valves.

2. Ultra-Compact & Lightweight Structure

     Miniaturized integrated design saves installation space, supporting vertical and horizontal flexible mounting. It is easy to embed in narrow workstations, compact jigs and automated production equipment.

3. Stable & Precise Pressure Output

     Equipped with high-precision pressure regulation mechanism, delivering fast response, low pressure ripple and continuous stable boosting pressure. It ensures consistent clamping force and precise pneumatic action for high-cycle automation lines.

4. Fully Pneumatic & Explosion-Proof

     100% pneumatic driving without electric components, realizing maintenance-free operation. Reinforced wear-resistant internal parts and high-quality sealing materials extend service life, adapting to flammable, dust and humid industrial environments.

5. Easy Installation & Zero System Upgrade

     Standard quick-connect air ports and simple debugging process support fast on-site installation. It realizes local pressure boosting directly without upgrading the whole factory main air supply system.

Typical Applications

     Ideal for scenarios requiring partial high pressure on standard 0.4–0.6MPa factory air systems, including automated production lines, automotive manufacturing fixtures, mechanical clamping equipment, mold cleaning devices, precision instrument pneumatic systems and compact industrial pneumatic stations.
